Laser Engraved calibration Grid with 10mm measurement markings
Real Grid XtoolF2
.xcs
Application scenario
Laser processing
Machine & module
xTool F2
5W, 15WCompatible xTool Machine
F1
2WMaterial used
Aluminum Sheet
21
1013
Information
This is a simple yet practical grid made on F2 (and should work fine for F1 as well).
Keep in mind, it’s a permanent mark on your machine plate, and if not done properly, you could permanently damage its aesthetics. Proceed at your own risk!
Enjoy!
