Laser Engrave & Score Black Steel Test Plate with Speed and Power Calibration
Instruction
Black Steel Engrave & Cut test grids
.xcs
Application scenario
Laser processing
Machine & module
xTool F1 Ultra
20WCompatible xTool Machine
M2
3W, 10W, 20WF2 Ultra UV
5WF2
5WP3
5WF2 Ultra
40W, 60WM1
5W, 10WD1
2WD1 Pro
2W, 40WF1
2W, 10WS1
2W, 10W, 20W, 40WF2 Ultra (Single)
60WMaterial used
304 Stainless Steel
12
866
Information
Exactly what it says!
Instruction
1
Step1: Testing
Preview
The image is just of the engraving, but there is also a cut test included in the file. Just position it over your material and set to go! Its pretty cool to see the different finishes you can get.
2
Step2
Preview
want to change the settings or remove some of the tests? just click ungroup and then you can either select and delete each section or change the parameters.
