Christmas Tree 3D Inner Engraving
Instruction
Christmas tree
.xcs
Application scenario
Laser processing
Machine & module
xTool F2 Ultra UV
5WMaterial used
K9 Inner Carved Glass
53
960
Information
I want to share with you my 3D inner engraving project. Please choose K9 glass‼️
Instruction
1
Step1: Replace the inner engraving lens
This step might be a little hard to finish and will take some time, but you can get it. Here is a tutorial on how to replace the lens:
2
Step2: Install the Riser
Preview
Install the riser to facilitate subsequent Inner Engraving Work Area Calibration and material placement.
3
Step3: Prepare 3D project files
Preview
Which support STL, OBJ, AMF, 3MF, GLB, PLY. You can generate 3D model via AImake
4
Step4: Inner engraving work area calibration
Tutorial:
- In the Select Processing Mode menu, choose Inner Engraving to access the Inner Engraving Settings.
- Inner engraving work area calibration
Inner Engraving Work Area Calibration
5
Step5: [Important]Testing!
Before starting a 3D inner engraving project, we need to test as much as possible. We can try different files on one piece of K9 glass. Once we get good results, use a clean piece of material for the formal processing.
