[Laser cut and engrave,Other] [How To] Christmas Deer 3D Inner Engraving — Project made with xTool F2 Ultra UV machine for Christmas.

[How To] Christmas Deer 3D Inner Engraving

Instruction

Christmas Deer

.xcs

Application scenario

Laser processing、Other (35min)

Machine & module

xTool F2 Ultra UV

Material used

K9 Inner Carved Glass

1513

Information

      Two deer are gazing at each other inside a clear crystal cube—could they be looking forward to Christmas?

P.S.: These two deer were crafted with different engraving techniques, by the way. Can anyone guess which ones?

Instruction

Step1: Christmas Deer 3D Inner Engraving

Preview

Hi everyone, this is the result I achieved. Now let me show you how to get the result step-by-step.😄

Step2: About the material: K9 glass

Preview

First, selecting the right material is a must! Some seemingly highly transparent crystal glass cannot actually be used for internal engraving.

For glass internal engraving, please choose K9 glass‼️

Step3: Preparations before processing

Replace the inner engraving mirror
Install the riser to facilitate subsequent Inner Engraving Work Area Calibration and material placement.
Prepare 3D source files： STL, OBJ, AMF, 3MF, GLB, PLY

The mirror installation process will take some time. Please install carefully.

Step4: Open xTool Studio

Preview

In the Select Processing Mode menu, choose Inner Engraving to access the Inner Engraving Settings.
Inner engraving work area calibrationInner Engraving Work Area Calibration

Step5: Testing

Preview

Before starting a 3D inner engraving project, we need to test as much as possible. We can try different files on one piece of K9 glass. Once we get good results, use a clean piece of material for the formal processing.
