[Laser cut and engrave] 3D Printed Glove Stand Holder for Kitchen Counter — Project made with xTool S1 machine for Laser cut and engrave.

Rubber Gloves Drying Stand

Instruction

Rubber Glove Drying Stand

.xcs

Application scenario

Laser processing

Machine & module

xTool S1

40W

Compatible xTool Machine

New

10W, 20W

F2 Ultra UV

15W

80W

F2 Ultra

40W

F1 Ultra

20W

5W, 10W

5W, 10W, 20W

D1 Pro

5W, 10W, 20W, 40W

55W

10W

10W, 20W

M1 Ultra

10W, 20W

P2S

55W

Material used

1/8"(3mm) Birch Plywood

579

Information

      I made this Rubber Gloves Drying Stand for my wife because her rubber gloves would never dry after washing dishes and the gloves would begin to smell. Plus, I didn’t want her to stop washing dishes.

Instruction

Step1

1. I started out by tracing her hand onto a piece of paper.

2. I scanned the hand into computer and imported it xTool studio. I removed the background and converted it to a vector image.

3. For testing using my S1 40 watt laser, I cut out the hand image from a piece of corrugated cardboard. It was then I realized a glove was hard to get onto the cardboard hand. That was due to the thumb which I then removed from the design.

4. In xTool Studio, I created and cut out the final design using Baltic Birch plywood.

5. I painted it gray to match our granite countertop.

6. I sprayed it with a clear coat satin lacquer for water proofing.

7. To give the project a bit of weight, I glued a gray molding tile underneath the base.
