Heart shaped Mum appreciation sign with Stand

Instruction
mum word cloud mothers day with stand and back engraving.xcs
mum word cloud mothers day with stand and back engraving
.xcs
Application scenario
Laser processing (30min)
Machine & module
xTool S1
20W
Compatible xTool Machine
M2
10W, 20W
F2 Ultra UV
5W
F2
15W
P3
80W
F2 Ultra
40W
F1 Ultra
20W
M1
5W, 10W
D1
5W, 10W, 20W
D1 Pro
5W, 10W, 20W, 40W
P2
55W
F1
10W
S1
10W, 40W
M1 Ultra
10W, 20W
P2S
55W
Material used
1/8"(3mm) Basswood Plywood
gift
22
610

Information

      This is a beautiful project for Mother's Day or any day to show your mum how much you love and appreciate her.


Instruction

1

Step1: Engrave the words and score the line around and the stand so that you can apply tape and keep cuts cleaner

Heart shaped Mum appreciation sign with Stand instruction: step 1 - Engrave the words and score the line around and the stand so that you can apply tape and keep cuts cleaner
Preview

I engraved and scored as the first step and then covered the score lines with tape before I cut them.  I was careful not to move the project while taping the score lines.

2

Step2: Cut after applying tape.

Heart shaped Mum appreciation sign with Stand instruction: step 2 - Cut after applying tape.
Preview

Turn output off on both the engrave and the score lines and turn output on for the cut lines.



3

Step3: Assembly

Heart shaped Mum appreciation sign with Stand instruction: step 3 - Assembly
Preview

Assemble the stand by placing the bottom piece through the larger piece with the small cut for the point of the heart at the front.



Optional - engrave a message on the back of the heart.
