Train d'engrenage réducteur - TP technologie5° - Collège Jean Marie Pelt
TP engrenages N°1 - Réducteur de vitesse
.xcs
Application scenario
Laser processing
Machine & module
xTool M1
10WMaterial used
Contre plaqué tilleul 3mm
2
60
Information
Je suis professeur de technologie en collège et j'ai créé se projet pour étudier les systèmes de transmission de mouvements avec mes élèves. Différents autres projets sont à venir
