Dutch Windmill Clock
Instruction
5802
.jpg
Show 14 more
Application scenario
Laser processing (120min)
Machine & module
xTool P2S
55WMaterial used
1/8"(3mm) Basswood Plywood
7
72
Information
I was asked to make one and I love putting personal touches to the things I make.
There are files for Lightburn and SVG files uploaded.
I will take more photos for assembly.
Instruction
1
Step1: Insrtuctions to come
Most of the parts are easy to put together. The most difficult part is the clock and blades assembly.
I'm going to make another and take pictures for assembly.
The clock face has some engraving for the numerals and there is a plate that is engravedthat goes behind the clock face.
2
Step2: build blades ring
There are four blades for this build, there is a 5 blade ring. Hit me up and I'll upload it.
there is a ring the the Y end of the blades go into. The 2 rings with the squares and points make a sandwich.
3
Step3: Assemble clock base
There was no base plate, so iI made one.
All of the pieces slide together.
Pictures and more detail to follow.
