Laser Cut Wooden Marble Maze Puzzle Game

Instruction

Wood Maze - Glass

.xcs

Show 3 more

Application scenario

Laser processing

Machine & module

xTool P2S

55W

Compatible xTool Machine

F2 Ultra UV

F2 Ultra（Single）

F2 Ultra

F1 Ultra

F1 Lite

M1 Ultra

D1 Pro 2.0

D1 Pro

Laserbox

Material used

1/8"(3mm) Basswood Plywood

1/8"(3mm) Clear Transparent Acrylic

1/2"(12mm) MDF

2180

Information

      This laser-cut marble maze is a fun and elegant tabletop puzzle made from wood and transparent acrylic.
Guide the marble through the maze by tilting the board and test your patience and dexterity!

The design is built from four layers, combining natural wood with a clear acrylic top panel that lets you see the maze while keeping the marble safely inside.
It’s a great gift idea, a decorative object, or a relaxing skill game for all ages.

The project is optimized for laser cutting and simple assembly, with optional 3D-printed marbles (or standard steel balls).

Instruction

Step1: Laser Cutting

Preview

Cut all parts from the provided files:

Bottom panel: wood, 3 mm thick
Maze layer: wood, 10 mm thick
Top panel: wood, 3 mm thick
Glass panel: transparent acrylic, thickness of your choice (3 mm used in this project)

Make sure to adjust settings according to your laser and material.

Step2: Assembly

Preview

Glue together the three wooden layers (bottom panel, maze layer, and top panel).

To ensure proper alignment during gluing, use the maze cut-out (the leftover piece from the maze layer) as a positioning guide. This helps keep the medium layer perfectly aligned.

Let the glue dry completely.

Place the acrylic panel on top and secure it using 4 × M2x6mm screws

You can adapt the hole size to match the screws you have available.
