Miraculous color sculpture "Mandala"
Instruction
Information
I had some hard-to-obtain 6mm thick pure titanium.
I was fascinated by color engraving and was able to accumulate a considerable amount of data.
To make use of that data, I decided to engrave it into 6mm thick pure titanium.
There is a front and back side, but this is the back side.
The result is a "mandala with mysterious colors."
Edited using the private version of XS.
In this version, the frequency (kHz) adjustment range has narrowed, display bugs have occurred, and editing takes time, so we have posted explanations for each canvas.
Please enjoy looking at them.
Google Translate
Instruction
Step1
Please note: The completion date for this work was made possible by upgrading from XCS to XS v1.1.10.
The XS I'm currently using is the "private version."
While organizing my files in preparation for this project, I discovered that the frequency (kHz) adjustment
range had narrowed.
The maximum pulse width (500ns) was changed to the maximum frequency (500kHz).
As a result, the original frequency (kHz) was not reflected and everything was converted to (500kHz).
Using the test grid in the first photo as a reference, check how wide a range you can get in frequency (...kHz)
for the current XS version when the pulse width (500ns) is used, and use the values you can get up to the
top of the test grid to find the right colour.
Unlike stainless steel, pure titanium produces a clear colour.
Give it a try and use it as reference.
A description is posted for each canvas.
