Tension knob crank
Crank for bandsaw tension
.xcs
Application scenario
Laser processing
Machine & module
xTool S1
40WMaterial used
3mm mdf
1
134
Information
This is a crank for the knob on my bandsaw to tension the blade. The knob is hard to reach and hard to turn when putting a lot of tension on the blade. I had a plastic one but it broke. This feels much more robust. I used a 7/8" dowel for a handle.
