[Laser cut and engrave] Wooden storage box with bear motif and rolling lid
Project made with xTool M1 Ultra machine for Laser cut and engrave.

Wooden storage box with bear motif and rolling lid

Instruction
RollTopBox.xcs
RollTopBox
.xcs
Application scenario
Laser processing (60min)
Machine & module
xTool M1 Ultra
20W
Compatible xTool Machine
New
M2
10W, 20W
F2 Ultra UV
5W
F2
15W
P3
80W
F2 Ultra
40W
F1 Ultra
20W
M1
5W, 10W
D1
5W, 10W, 20W
D1 Pro
5W, 10W, 20W, 40W
P2
55W
F1
10W
S1
10W, 20W, 40W
M1 Ultra
10W
P2S
55W
Material used
1/8"(3mm) Basswood Plywood
gift
37
1110

Information

      I am engraving a bunch of golf tees and needed a place to store them. I've always been fascinated with live hinges and wanted to make this box to hold the finished tees, hence the name, The Tee Box on the front. The fingers are tight so they can hold together prior to glue.
#box#
storage
container
roll top box
roll top

Instruction

1

Step1

Wooden storage box with bear motif and rolling lid instruction: step 1 -
Preview

Cut out all items and prepare to put them together. The fit is tight on all of the fingers. I designed it this way because I hate having too much slack when fitting.

2

Step2

Wooden storage box with bear motif and rolling lid instruction: step 2 -
Preview
Wooden storage box with bear motif and rolling lid instruction: step 2 -
Preview
Wooden storage box with bear motif and rolling lid instruction: step 2 -
Preview

Put the sides, bottom and curved edges together.

3

Step3

Wooden storage box with bear motif and rolling lid instruction: step 3 -
Preview
Wooden storage box with bear motif and rolling lid instruction: step 3 -
Preview
Wooden storage box with bear motif and rolling lid instruction: step 3 -
Preview
Wooden storage box with bear motif and rolling lid instruction: step 3 -
Preview

Place the pull handle on the side of the roller that you want, place rails on box and the curved edge for the roller to go under the false bottom. Be careful with the glue and lubricate the wood rails for easy gliding.

4

Step4

Wooden storage box with bear motif and rolling lid instruction: step 4 -
Preview
Wooden storage box with bear motif and rolling lid instruction: step 4 -
Preview

Finish placing the roller, second bottom, and all other items and ensure the roller top moves on the rails properly.
