Laser Cut Black Butterfly Wall Art Decor

Instruction
butterfly.xcs
butterfly
.xcs
Application scenario
Laser welding / cleaning
Machine & module
xTool MetalFab Laser Welder
1200W
Material used
3mm stainless steel
38
354

Instruction

1

Step1

Step 1 Connect the machine, place the material
Open and connect the welding machine to the cutting platform, then plug on, turn on the gas(air compressor or nitrogen cylinder over 174 PSI/1.2 MPa or set the xTool air compressor with dryer at the highest pressure of 145 PSI/1.0MPa while xcs will show 0.5-0.7MPa when processing when using telescopic cutting nozzle).
Place a 24''x 24''(610 x 610 mm) sheet on the cutting platform and secure it with the blade and clamps.
2

Step2

STEP 2. Insert the XCS file
Turn on the machine, open xTool Creative Space on the computer, drag in the required xcs file, and adjust the parameters.

Parameters for 1/8'' (3mm) Stainless Steel:

Use the right nozzle and gas: ordinary nozzle + 1.2MPa pressure or Telescopic nozzle + 0.5~0.7MPa
Defocus Distance
For ordinary nozzle: -6~-7
For telescopic nozzle: -5~-6
3

Step3

STEP 3. Calibrate the capacitive sensor
Click the start calibration button and then click on the center area of the material image to perform calibration.
4

Step4

STEP 4. Framing and Processing
Click the "Framing" to confirm that it is within the processing range. If there are no issues, close the lid, click "Process" and press the "Start" button of the cutting platform.
