Unique Modern Letter-shaped Metal Chair

• Open and connect the welding machine to the cutting platform, then plug on, turn on the gas(air compressor or nitrogen cylinder over 174 PSI/1.2 MPa or set the xTool air compressor with dryer at the highest pressure of 145 PSI/1.0MPa while xcs will show 0.5-0.7MPa when processing when using telescopic cutting nozzle).
• Place a 24''x 24''(610 x 610 mm) sheet on the cutting platform and secure it with the blade and clamps.

• Turn on the machine, open xTool Creative Space on the computer, drag in the required xcs file, and adjust the parameters.

Parameters for 1/5'' (5mm) Stainless Steel：

• Refer to the built-in settings in Easyset Library of XCS of 5mm Carbon Steel

• Defocus Distance

• Switch to the nitrogen cylinder and set the pressure to 14.5-29 PSI(0.1-0.2 MPa).
• Disconnect the wiring between the welding machine and the cutting platform
• Remove the capacitor head from the welding gun and install the welding nozzle.
• Install the welding wire and connect the workpiece sensing cable onto the metal part that needs to be welded to complete the circuit.

• Choose the material 1/5'' (5mm) Stainless Steel to apply the built-in welding parameters, and proceed with welding (Must enable wiring and lasering)
• Pause welding at key points first and then use continuous welding for stronger connection

• Before cutting, you must correct the red light and confirm the zero-focus position or it will cause bad cutting effects.
• For 5mm-Stainless Steel cutting, you must set the lead-in lines and enable the soft-start for best cutting results.
• Please choose the correct cutting nozzle and gas pressure: Ordinary nozzle requires pressure over 174 PSI/1.2 MPa of Nitrogen or compressed air. If the air pressure is only about 87 PSI/0.6MPa, must use the telescopic cutting nozzle.
• It is recommended to conduct a small-scale test before cutting and welding to confirm the results before proceeding with further processing.
