Self centered alignment tool
Návod
Selfcenteredalignmenttool22.01.2025V1
.xcs
Aplikační scénář
Laser processing (10min)
Stroj a modul
xTool S1
40WKompatibilní · 13
Použitý materiál
1/8"(3mm) Basswood Plywood
54
848
Návod
1
Krok1: Cut it
Náhled
Cut the two pieces out
2
Krok2: Glue it
Náhled
Náhled
Glue it together and insert the two M4 nuts
3
Krok3: Assamble it
Náhled
Náhled
Screw the screws into the nuts from the other side. Done
4
Krok4: Execution
Náhled
Náhled
Náhled
Náhled
Push the tool with the screws flush against your workpiece, as shown in image 1. Then, insert a pencil into the top hole and draw an even line on the workpiece by moving the tool from top to bottom while ensuring that the screws remain in constant contact with the workpiece.
