Divine Relief Coaster – Depth Engraved 3D Wooden Art

Instruction
This project is empowered by AImake
Durga Relief Engraving.xcs
Durga Relief Engraving
.xcs
Application scenario
Laser processing (120min)
Machine & module
xTool M1 Ultra
20W
Compatibles · 13
Accessories
xTool M1 Riser Base with Honeycomb Panel
xTool M1 Air Assist Set
Material used
Beechwood Coasters
gift
47
575
Source Image Generated with AImake
Tap to View Prompt and Remix It!
atomm-ai-image
view prompt

Information

      Bring sacred art to life using depth mapping and precision laser engraving. In this tutorial, I’ll show you how to transform a 2D image into a stunning 3D relief engraved wooden coaster using a diode laser.

This project combines digital depth mapping, relief carving, and controlled burn techniques to create a premium handcrafted finish.

✨ Why This Project Stands Out

🔸 Converts flat artwork into 3D sculpted relief
🔸 Professional depth-map engraving workflow
🔸 Perfect for gifting, décor, or premium product lines
🔸 Works beautifully on basswood
🔸 High perceived value with minimal material cost

This is not a simple surface engraving — this is layered depth carving.

🛠 Materials Used

🔸 3mm – 6mm Basswood
🔸 Diode Laser (I used xTool M1 Ultra)
🔸 Depth Map Image (grayscale)
🔸 Light sanding paper (320–400 grit)
🔸 Optional: Wood oil or clear varnish
laser engraving
depth map
depth engraving
3d wood carving
relief engraving 3d
relief engraving
elegant
grayscale engraving
laser engraved
tabletop display

Instruction

1

Step1: Prepare the Artwork

1️⃣ Start with a high-resolution image.
2️⃣ Convert the image into a grayscale depth map.

  • White = highest point
  • Black = deepest cut
  • Mid-tones = layered relief

Important: Smooth gradients create smooth relief transitions.

2

Step2: Depth Mapping Strategy

Instead of simple line engraving, we use:

✔ Power variation
✔ Speed variation
✔ Multi-pass engraving
✔ High DPI for smooth surface blending

This creates a sculpted 3D appearance rather than flat shading.

3

Step3: Laser Settings (Example Starting Point)

These will vary depending on wood density and machine calibration.

For Basswood (Relief Mode):

• Power: 60–100%
• Speed: 100–400 mm/s
• Passes: 1–3 depending on depth
• DPI: 300+

Tip: Always test on scrap wood first.

4

Step4: Engraving Process

1️⃣ Secure the wood flat.
2️⃣ Import grayscale depth map.
3️⃣ Set engraving mode to grayscale or relief.
4️⃣ Run a small test section first.
5️⃣ Proceed with full engraving.

You’ll notice gradual layering forming the sculpted effect.

5

Step5: Finishing Touch

After engraving:

✔ Lightly sand surface to smooth micro-burn fibers
✔ Remove dust with soft brush
✔ Apply light wood oil for warm tone
✔ Optional: Clear matte varnish

This enhances contrast and highlights depth.
