Personalized Laser Engraved Dog Tag with Custom Portrait and Name
Instruction
635a0e36_1024px
.png
Show 3 more
Application scenario
Laser processing (22min)
Machine & module
xTool F2
5WMaterial used
1.7mm Silver Stainless Steel Tag
14
Information
First deer ever killed from my niece. Created her a dog tag from SS from the portrait of her first deer as a keepsake.
Instruction
1
Step1: Prepare SS tag
Prep SS tag with alcohol and lint free cloth
2
Step2: Placed on base plate and ensured both lights were aligned center of the tag to begin and ensure accuracy.
Preview
Placed on base plate and ensured both lights were aligned center of the tag to begin and ensure accuracy.
3
Step3: Imported image, updated setting to picture as described. (settings based on test array)
Preview
Preview
Imported image, updated setting to picture as described. (settings based on test array)
4
Step4: Auto focused machine, refreshed twice before starting process.
Defined settings as Dot duration at 1310, power at 95, DPI at 940. 1 pass, bitmap mode as Jarvis, engraving Bi-directional.
