Detailed Color Chart - Engraving Grid Test For Water Based Paint or Stain - Wood/Plywood
Instruction
Water Based Exterior Paint Grid Test
.xcs
Application scenario
Laser processing (11min)
Machine & module
xTool P2
55WCompatibles · 12
Material used
1/8"(3mm) Basswood Plywood
1/4"(6mm) Basswood Plywood
1/4"(6mm) Birch Plywood
1/8"(3mm) Birch Plywood
1
8
Information
Test a wide range of settings to ensure your engraves get through the wood stain. Use the colour chart to select the right settings to produce high contrast engraves on painted wood. Tested on water based low VOC paint
Instruction
1
Step1
Add your wood to the machine and use the built-in camera (or positioning system) to show the software where the wood is
2
Step2
Check your exhaust is vented outside
3
Step3
When ready, hit start on the software, then hit the button on the machine. Do not leave the machine unnatended whilst in use
4
Step4
After processing has completed, remove the material and wipe with alcohol gently if needed to remove soot. Do not sand the wood as it will remove the paint.
5
Step5
Check the colour chart, and if needed, adjust the settings and run it again
