Laser Cut Star Wars Galaxy Map Wooden Wall Art
Instruction
Information
This project etches a high-fidelity, vintage-style map of the Star Wars galaxy. The design features "Unknown Regions," major hyperspace lanes, and key planetary systems, rendered with a woodcut aesthetic. Perfect for wall art, coaster centerpieces, or strictly decorative intel for your rebel base.
Instruction
Step1: Galactic Nav-Chart (Vintage Cartography Edition)
This project etches a high-fidelity, vintage-style map of the Star Wars galaxy. The design features "Unknown Regions," major hyperspace lanes, and key planetary systems, rendered with a woodcut aesthetic. Perfect for wall art, coaster centerpieces, or strictly decorative intel for your rebel base.
Bill of Materials (BOM):
Substrate: 3mm (1/8") Basswood Plywood.
Hardware: xTool S1 (10W/20W/40W - Settings below are calibrated for 40W diode; adjust accordingly).
Auxiliary: Honeycomb panel (essential for airflow).
Fabrication Protocols (xTool Creative Space):
1. Image Processing:
Bitmap Mode: Grayscale (Critical for the vintage, shaded depth).
Resolution: 180 Lines per cm (High density for small text clarity).
2. Laser Parameters (Engrave):
Power: 45%
Speed: 200 mm/s
Pass: 1
Mode: Bi-directional
3. Vector Cut (Outline):
Note: Ensure you have a vector outline set for the outer rim.
Power: 100%
Speed: 4-6 mm/s (depending on wood density).
Post-Processing:
Cleaning: Use a soft bristle brush or compressed air to remove soot from deep etchings.
Finishing: A light sanding with 400-grit to pop the highlights, followed by a clear matte spray to seal the char.
