DisplayShelf for building brick speed cars
Instruction
Display Shelf
.xcs
Application scenario
Laser processing
Machine & module
xTool M1
10WCompatibles · 13
Accessories
xTool M1 Air Assist Set
xTool Smoke Purifier
Material used
1/8"(3mm) Basswood Plywood
1
60
Information
Simple shelf to display building block collection of speed cars.
Just needs 2 sheets of 3mm plywood and wood glue.
Instruction
1
Step1: Cut materials in machine
Cut materials on the machine. There's two layouts each sized to a 12"x12" sheet.
I added a .083mm kerf to the project so that the joints should fit nice and tight.
2
Step2: Glue shelves and front edge together
For assembly, the first step is to assemble the front edge to the shelf. Repeat 5 times.
Ensure to add wood glue to the tabs. If the pieces are tight, I use a hand clamp to squeeze the parts together. Using a hammer or a rubber mallet works, but the hand clamp wont cause damage like the hammer/mallet.
3
Step3: Glue all shelves to one side
Assemble all 5 shelves to one vertical side.
4
Step4: Add the other side to complete the assembly
Assemble the remaining side.
