Decorative Arabesque – Wooden Box Details
Instruction
Caixa arabesco
.xcs
Application scenario
Laser processing
Machine & module
xTool M1 Ultra
10WCompatibles · 14
Accessories
xTool M1 Riser Base with Honeycomb Panel
Material used
1/8"(3mm) Walnut Plywood
4
114
Information
This instruction defines the standard process for laser cutting decorative arabesque designs in walnut plywood using the xTool M1 Ultra (10W diode laser).
The process includes proper file preparation, dimensional adjustment based on the wooden box used as the base product, secure material fixation using a honeycomb bed and magnets, and validated cutting parameters (90% power, 5% speed).
Note:
The provided design file contains three (3) instances of the arabesque pattern for layout convenience. These duplicated designs may be deleted, duplicated, or repositioned as needed, according to the preference, material size, or production requirements.
Instruction
1
Step1: Machine Setup
Power on the <xTool M1 Ultra and install the honeycomb bed
Place the walnut plywood on the honeycomb and secure the material using magnets
- Ensure that the material is flat / no movement during cutting
Open xTool Creative Space and import the arabesque file, resize the sesign to match the base product.
Perform Auto Focus
Run frame to confirm the area.
2
Step2: Cutting Parameters
Power: 90%
Speed: 5%
Passes: 1
Air Assist: ON
If cut is not complete:
- Perform an additional pass without repositioning the material
- Or apply a validated parameter adjustment
3
Step3: Cutting Operation
Confirm cutting parameters in XCS
Start the laser cutting process
Continuously monitor the operation
Upon completion, wait 30-60 seconds
Carefully remove the cut parts and scrap
4
Step4: Quality Inspection
Acceptance criteria
- Fully cut-through design
- Arabesque intact, no broken features
- Clean edges with no excessive charring
- Dimensions match adjusted design
- Proper fit to the base box
5
Step5: Finishing (If Applicable)
- Light sanding of edges (grit 220-320)
- Remove soot or residue
- Apply sealer, varnish, or finish as specified
- For overlay designs, glue after finishing
