Glass Baking Dish with Laser Engraved Baked With Love Design
Instruction
Information
This download includes both a standard and an inverted version of the design. The inverted image is intended for engraving on the underside of glass casserole dishes, allowing the design to be read correctly from above.
Instruction
Step1
Laser Engraving Instructions
Deep-Dish Pyrex Glass Casserole (Bottom Engrave, Read from Above)
This process was used specifically on a deep-dish Pyrex glass casserole with the design engraved on the underside so it is visible from above during use.
Preparation
Mask the dish
Tape off the sides and handles, leaving only the flat bottom surface exposed for engraving.
Apply paint mask
Spray the exposed bottom with black spray paint, applying a slightly heavier coat than average, but not excessively thick. Allow to dry completely.
Position the dish
Place the casserole dish upside down on the laser bed.
Set height and focus
Raise or lower the tray to accommodate the dish depth.
Move the laser head over the center of the dish and set proper focus.
Frame the job
Mark your work area to ensure proper placement.
Note: Any outer box in the file is used only for centering and alignment and should be set to “Ignore.”
Laser Settings
Machine: xTool S1 – 40W
Power: 70%
Speed: 80
Lines: 180 LPI (LCM)
Cleanup & Finishing
Remove the paint mask using 90% isopropyl alcohol.
Wash the dish in the dishwasher on the sanitize cycle to fully clean and set the engraving.
Final Result
The engraving is permanently etched into the underside of the glass, making it:
Food-safe
Dishwasher-safe
Protected from wear
Clearly visible from above during use
Enjoy your finished piece!
