Making a Right Angle Jig for my P3
Instruction
Untitled
.xcs
Show 1 more
Application scenario
Laser processing
Machine & module
xTool P3
80WCompatibles · 12
Material used
1/8"(3mm) Basswood Plywood
4
Information
Right angle Jig for the P3 to set up items on the cutting rails Square and into the same location.
Instruction
1
Step1
Very simple design using the xtools program. I used the rectangle Shape and united them to each other creating the square. then glued a couple pieces of scrap Bass wood to the bottom to create a support surface. Then use the provided clamps to hold it to the slats. now each piece i place for this project will be in the exact same location.
