[Laser cut and engrave] Engraving on copper sheets — Project made with xTool F1 machine for Laser cut and engrave.

Engraving on copper sheets

Instruction

Coppe Engrave Lady and Dog

.xcs

Application scenario

Laser (160min)

Machine & module

xTool F1

Material used

Copper

Metal

3214

Information

      Copper is fickle and it has taken me about 50 of these 4x4 engravings to get the settings right. Imaged were created with the AI feature in the XCS software. XCS File Included Below.

Copper

Instruction

Step1: Sand copper sheet with 220grit sand paper, spray with metal degreaser and scrub well.

Sand well and degrease with a metal degreaser. I use the degreaser from sculpt Nouveau. Any grease from your fingers or other source will stop the laser from marking properly.

Step2: Dry well and spray will brilliance laser marking spray.

I have tried all the laser sprays and brilliance works best on copper. You can mark copper without spray, but you will be much better results with it.
