[Laser cut and engrave] 3mm shape cut out with stand — Project made with xTool F2 machine for Laser cut and engrave.

3mm shape cut out with stand

Instruction

shape1withstand.xs

shape1withstand

.xs

Application scenario

Laser processing

Machine & module

xTool F2

5W, 15W

Compatible xTool Machine

M2

3W, 10W, 20W

F2 Ultra UV

5W

P3

5W, 80W

F2 Ultra

40W, 60W

F1 Ultra

20W

M1

5W, 10W

D1

2W, 5W, 10W, 20W

D1 Pro

2W, 5W, 10W, 20W, 40W

P2

55W

F1

2W, 10W

S1

2W, 10W, 20W, 40W

M1 Ultra

10W, 20W

P2S

55W

F2 Ultra (Single)

60W

Material used

1/8"(3mm) Black Acrylic

gift

3

241

Information

      Use this to cut out a shape to be laser engraved with the F2 5w IR

Instruction

1

Step1: Remove the film and do not resize

Remove film and do not resize. Resizing will prevent the main shape not to fit in the stand.

2

Step2: try to center the object you are cutting as much as possible .

center the piece you are cutting in the middle of the base plate

3

Step3: Cut one piece at a time

cut the main piece separate from the others.

4

Step4

optional to stack the stand pieces for more stability and then use your choice to glue/adhere it
