This is a jig I made to hold 3 mm basswood securely to the Amazon bed for the M2.
This is the bed I use:
https://www.amazon.com/dp/B0GCGHLM5R?ref=ppx_yo2ov_dt_b_fed_asin_title&th=1
It may also work with other beds, though I haven't tested them.
You'll also need M4 or M5 T-slot nuts, such as these:
https://www.amazon.com/dp/B0DZH4HCF1?th=1
