L-shaped magnetic corner alignment squares for laser projects.
Secure parts to honeycomb
.xs
Application scenario
Laser processing
Machine & module
xTool S1
20WCompatible xTool Machine
P3
F2
F2 Ultra UV
F2 Ultra
F1
P2S
P2
M1 Ultra
M1
D1 Pro
D1
M2
Material used

1/8"(3mm) Basswood Plywood
221
3251
Information
You can use these on corners or simply to hold the sides of your material in place. Glue the two layers together and add your magnets. The magnets were from a Big Box hardware store, Neodymium Disc Magnets. .315" x .118 ". I recommend that you measure the magnets prior to burning the holes.
