Husky Dog In Crystal Sphere

Prism Master Award in Turn Memories into Timeless Crystal

Instruction

husky_jorik

.xcs

Application scenario

Laser processing

Machine & module

xTool F2 Ultra UV

Material used

K9 Glass Crystal Ball

543

Information

      The younger of my two huskies, who is unfortunately no longer with me, immortalized in a glass sphere.

https://www.facebook.com/eridan.jora/posts/pfbid02iyWuPhi1Sntz43UURxAZNAKvCCMQDtwdKmbvd2vny73QNXdmtzZx9T2MhkPcGC5Yl

Instruction

Step1: Necessary accessories

I used the original "K9 Crystal Ball Inner Engraved Kit" accessory for the inner engraving of the glass ball.

If you don't have the original set, you will need to use a replacement set.
You will need a beaker or mug that the glass ball will fit comfortably in. You will also need a stand to hold the ball in the center of the beaker. You can design and 3D print this part or laser cut it out of acrylic.

Step2: Glass preparation

Clean the sphere thoroughly. Use gloves and a cloth with IPA. Then place the sphere in your beaker. Pour the oil over the sphere carefully so that no bubbles form. You can use the original XTool inner engraving oil, or pure paraffin oil, for example for massages. If you are not using the original accessory, you need to measure the height of the bottom of the sphere above the base on which the beaker stands and also the height of the oil level. Place the beaker in the center of the work surface for inner engraving.

Step3: Laser settings

Set all the necessary parameters of your ball, such as diameter (my ball was 60 mm in diameter), height above the surface, oil level, as required by the inner engraving settings. I tried to select the preset material "K9 Glass Crystal Ball" as the material, but the settings did not load correctly. So I used "K9 Inner Carved Glass". Then just start the process and enjoy.
