Leather stamping tools storage

Instruction
Closed box leather stamp storage.xcs
Closed box leather stamp storage
.xcs
Application scenario
Laser processing
Machine & module
xTool S1
20W
Compatible xTool Machine
New
M2
10W, 20W
F2 Ultra UV
5W
F2
15W
P3
80W
F2 Ultra
40W
F1 Ultra
20W
M1
5W, 10W
D1
5W, 10W, 20W
D1 Pro
5W, 10W, 20W, 40W
P2
55W
F1
10W
S1
10W, 40W
M1 Ultra
10W, 20W
P2S
55W
Material used
1/8"(3mm) Basswood Plywood
gift
13
626

Information

      I created a closed box system to store, and make accessible, my leather stamping tools. Each closed box has holes sized to accept the stalk of various sized stamping tools with an approximately 100mm long stalk. There is a hole in the base to allow retrieval of the smaller headed tools that may fall through, I'm thinking of putting in a piece of grooved foam to stabilize the tools. The boxes are stackable and with the heads pointing toward you, it's easier to pick out the ones required for the job. Minimal real estate on your work surface is used and it's saved me from digging through cups of stamping tools.


Instruction

1

Step1

These are set up to use 12"/300mm square sheets of 3mm ply. It is a very basic symmetrical box so sides are interchangeable and it's glued together on the tabs. The explanatory text is set to not print, everything else is a cut. The holes are placed on the front panel above the center line and the large hole in the base is for tool access when/if they fall through.
