Lindensperrholzplatte
3 mm Lindensperrholzplatte, Xtool S1
MachineS1(Blue light · 20W)
Processing ModeProcess on baseplate
Processing typeCut
Thickness3mm
SettingsPass1
Speed7mm/s
Power75%
Number of tabs2
Tab spacing100mm
Generateby number
Tab size0.5mm
Laser typeBlue light
Overcut size0.5mm
Focus descent distance3mm
Focus descent per step3mm
Initial focus descent distance3mm
Descent interval (descent every N layers)1
sinkingMethodone
Pass1
Speed7mm/s
Power75%
Number of tabs2
Tab spacing100mm
Generateby number
Tab size0.5mm
Laser typeBlue light
Overcut size0.5mm
Focus descent distance3mm
Focus descent per step3mm
Initial focus descent distance3mm
Descent interval (descent every N layers)1
sinkingMethodone
Version: 2.0.0
Parameter ConverterLimited-time Free
Convert to My Machine Parameters0
Did these settings work?8 makers tried these settings
+8
8worked
0didn't work
